160 QXS G2 Hardware Installation and Maintenance Guide
Tabl e 4 5 provides a list of CRUs in the 5U84 RAID chassis/expansion chassis.
NOTE: Figure 124 on page 162 provides a representative example of the controllers used in the
RAID chassis.
Figure 125 on page 163 provides a representative example of the IOMs used in the expansion chassis.
The QXS-G2-412, QXS-G2-424, and QXS-G2-484 systems use the same identical controllers and IOMs.
5U84 RAID Chassis CRUs (Rear View/Two CNC Controllers)
NOTE: Depending on customer requirements, the controllers can be CNC (FC or iSCSI)) for host
connection.
Ta b l e 4 5 5U84 RAID Chassis/Expansion Chassis CRUs
Item Chassis Component Description
Disk Drive in
Carrier (DDIC)
DDICs must be installed into drawers after delivery
• 2.5" disk with 3.5" adapter (disks of differing type/speed and storage capacity: SAS, SSD)
• 3.5" disk (disks of differing type/speed and storage capacity: SAS, SSD)
Additional CRUs Not Shown
Chassis Sheet metal chassis that is configurable as a RAID or expansion chassis
SFP* Small form-pluggable (SFP) connectors
SFP transceiver: 8/16Gb/s FC; 10GbE iSCSI; 1Gb/s iSCSI
Rail Kit Variable attachment options
5U rack mount kit, shelf, long, all hardware
Cable Kit Cable kit [Cable package: standard HD mini-SAS (SFF-8644) to HD mini-SAS (SFF-8644)]
Cable kit [Cable package: standard HD mini-SAS (SFF-8644) to mini-SAS (SFF-8088)]
Cable kit [Cable package: USB Type B; CLI (USB)]
AC Power
Cord
AC power cord compatible with AC PSU(s)
*QXS-484 G2 RAID chassis support FC and iSCSI SFPs used in combination.
