Installation 79
5U84 Two Servers/One HBA Per Server/Dual Path
Figure 74 provides an illustration of connecting a 5U84 to two servers/one HBA per server, with dual
path.
Figure 74 5U84 Two Servers/One HBA Per Server/Dual Path
2U12/2U24 Four Servers/One HBA Per Server/Dual Path
Figure 75 provides an illustration of connecting a 2U12/2U24 to four servers/one HBA per server, with
dual path.
Figure 75 2U12/2U24 Four Servers/One HBA Per Server/Dual Path
5U84 RAID Chassis
Server 1
2U12/2U24 RAID Chassis
0B
Server 2
0A
Server 4
Server 3
To Next Page
