Quantum QXS G2 Series

82 QXS G2 Hardware Installation and Maintenance Guide
2U12/2U24 Four Servers/Multiple Switches/SAN Fabric
Figure 80 provides an illustration of connecting a 2U12/2U24 to four servers, multiple switches, and a
SAN fabric.
Figure 80 2U12/2U24 Four Servers/Multiple Switches/SAN Fabric
5U84 Four Servers/Multiple Switches/SAN Fabric
Figure 81 provides an illustration of connecting a 5U84 to four servers, multiple switches, and a SAN
fabric.
Figure 81 5U84 Four Servers/Multiple Switches/SAN Fabric
2U12/2U24 RAID Chassis
Server 1 Server 2
0A
0B
SAN
Server 3
Server 4
5U84 RAID Chassis
Server 1 Server 2
0A
0B
SAN
Server 3
Server 4
