Quectel LTE-A Module Series User Manual

LTE-A Module Series
EM120R-GL&EM160R-GL Hardware Design
EM120R-GL&EM160R-GL_Hardware_Design 22 / 79
domain.
67
RESET#
RESET#
DI
WWAN reset input
Active low.
Pulled up
internally.
1.8 V power
domain.
68
SUSCLK (32kHz)
ANT_CONFIG
DI
Antenna configuration
Pulled up
internally.
1.8 V power
domain.
69
CONFIG_1
CONFIG_1
Connected to GND
internally
70
3.3V
VCC
PI
Power supply
Vmin = 3.135 V
Vnorm = 3.7 V
Vmax = 4.4 V
71
GND
GND
Ground
72
3.3V
VCC
PI
Power supply
Vmin = 3.135 V
Vnorm = 3.7 V
Vmax = 4.4 V
73
GND
GND
Ground
74
3.3V
VCC
PI
Power supply
Vmin = 3.135 V
Vnorm = 3.7 V
Vmax = 4.4 V
75
CONFIG_2
CONFIG_2
NC
Please keep all NC, reserved and unused pins unconnected.
NOTE
