Quectel LTE-A Module Series User Manual

LTE-A Module Series
EM120R-GL&EM160R-GL Hardware Design
EM120R-GL&EM160R-GL_Hardware_Design 33 / 79
Table 10: Pin Definition of (U)SIM Interfaces
EM120R-GL&EM160R-GL support (U)SIM card hot-plug via the USIM_DET pin, which is a level trigger
pin. The USIM_DET is normally short-circuited to ground when (U)SIM card is not inserted. When the
(U)SIM card is inserted, the USIM_DET will change from low to high level. The rising edge will indicate
insertion of the (U)SIM card. When the (U)SIM card is removed, the USIM_DET will change from high to
low level. This falling edge will indicate the absence of the (U)SIM card.
Pin Name
Pin No.
I/O
Description
Comment
USIM1_VDD
36
PO
Power supply for (U)SIM1 card
Either 1.8 V or 3.0 V is
supported by the module
automatically.
USIM1_DATA
34
IO
(U)SIM1 card data
USIM1_CLK
32
DO
(U)SIM1 card clock
USIM1_RST
30
DO
(U)SIM1 card reset
USIM1_DET
66
DI
(U)SIM1 card insertion detection.
Active high.
Internally pulled up.
When (U)SIM1 card is
present, it is at high level.
When (U)SIM1 card is
absent, it is at low level.
USIM2_VDD
48
PO
Power supply for (U)SIM2 card
Either 1.8 V or 3.0 V is
supported by the module
automatically.
USIM2_DATA
42
IO
(U)SIM2 card data
USIM2_CLK
44
DO
(U)SIM2 card clock
USIM2_RST
46
DO
(U)SIM2 card reset
USIM2_DET
40
DI
(U)SIM2 card insertion detection.
Active high.
Internally pulled up.
When (U)SIM2 card is
present, it is at high level.
When (U)SIM2 card is
absent, it is at low level.
