Radiolink Electronic Ltd
www.radiolink.com
Adjustability:
• channels 5-8 may be assigned to any SWITCH (A-H), LOGIC SWITCH (Lsw1-Lsw3), slider
[VR(D) and VR(E)], or knob [VR(A-C)] (for example, moving flaps to a switch or slider), but not the
primary control sticks (use programmable mixes to do so);
• channel 9-10 may be assigned to any SWITCH (A-H), LOGIC SWITCH (Lsw1-Lsw3) and the
servo direction may be changed.
• multiple channels may be assigned to the same switch, slider or knob;
• channels set to "NULL" are only controlled by mixes. (Ex: utilizing 2 channels for 2 rudder servos.
See mixes p. 68.)
• If GYRO SENSE, GOVERNOR, and THR-NEEDLE functions are activated, AUX-CH settings of
related channels become invalid automatically.
CH1：STK1
CH2：STK2
CH3
：
STK3
CH4：STK4
CH11：SwD
CH12
：
VrE
CH5：SwG
CH6
：
VrA
CH7
：
VrC
CH8：VrB
CH9：SwB
CH10
：
SwA
Related channels:
GYRO SENSE (ACRO): CH. 5, 7, or 8
GYRO SENSE (HELI): CH. 5
GOVERNOR (HELI): CH. 7, or CH. 7 and 8
THR-NEEDLE (ACRO HELI): CH. 8
Remember that if you assign primary control of a channel to a switch which you later use for
other functions (like dual/triple rates or airbrakes), every time you use that other function you will
also be moving the auxiliary channel.
Assign flaps to the right
slider[VR(E)] and set
channel 7 to NULL in
preparation to use it as a
smoke system control
(the smoke system being
activated later by a
throttle to CH7 MIX).
Open BASIC menu, then to
AUX-CH
for 1s .(If ADVANCE again) .
to AUX-CH,PUSH
Choose channel to change (Ex:CH6)
to CH6，PUSH， to desired switch,
PUSH
Repeat above steps as desired.
(Ex:CH7=NULL)
2.3.12 TIMER sub-menu (stopwatch functions):
Controls three electronic clocks used to keep track of time remaining in a competition time allowed,
flying time on a tank of fuel, amount of time on a battery, etc.
