RadioLink AT10II User Manual

Radiolink Electronic Ltd
www.radiolink.com
74
Goals
Steps
Inputs
Fine-tune hovering with the hovering
adjustments. Remember these affect
only the hovering (normal) condition.
Adjust throttle and collective pitch
curves until model hovers nicely. In
flight,adjust collective pitch and
throttle
curves near hover point independently
with
HOV-THR
and
HOV-PIT
knobs.
Store new settings after flight.
Open the
HOV-THR
function
to BASIC. again to
ADVANCE
,
to HOV-THR.
Optional: change which
knob adjust
search hovering
curve.
NULL
locks in
curve
in last stored position.
to VR , to desired
knob and direction
Close
Open the
HOV-PIT
function.
to HOV-PIT. Repeat.
Close
5.3.6 HIGH/LOW PITCH (HI/LO-PIT):
This function may be used to adjust the curves high and low side individually for each flight
condition (normal, idle-up 1, idle-up 2, idle-up 3, throttle hold).
ADJUSTABILITY:
• You may define high and low side rate trim knobs (the high side pitch trim control is defined as the
right side lever at initial setting).
• The conditions are activated in the CONDITION SELECT function.
• Both adjustments may be set to MANUAL, temporarily turning off the knob.
• Adjustments may be memorized and then return the knobs to center point to use that amount of
adjustment, allows easy use of the trimming knobs for multiple models.
Goals
Steps
Inputs
Set up a high pitch curve
in the idle-up 1condition.
Open the HI/LO-PIT
to BASIC menu, again to ADVANCE menu.
to HI/LO-PIT.
Select the idle-up 1 condition
to COND , to IDL1
Set the rate (Ex:80%)
to HI-PIT ,
to
80%
Optional：Change which knob
adjusts high pitch curve.
to VR , to desired knob and direction.
Close
