RadioLink AT10II User Manual

Radiolink Electronic Ltd
www.radiolink.com
78
governor settings
automatically when changing
conditions. Consider setting the
battery Fail Safe settings and
other helpful functions on the
governor itself.
Activate the function.
to MIX ， to ACT.
Opt ional : change cu t- off
cha nn e lto channel 8 and
assign switch and direction
for on/off (channel 8).
to -cut- CH: ， to+CH8，
to -cut-SW ， to desired SW
Optional: Changes switch
assignment to select governor
settings.
Ex : se lec t sw itc h that
sele ct s th econditions.
to SW ， to Cond，
Adjust governor speed
settings perswitch position
or condition as needed.
(Ex: defaults are fine.)
Allows head speed
adjustment from transmitter.
to each Cond position or as
needed.
to next Cond，repeat .
Close
5.3.10 Throttle Mixing (THROTTLE MIX):
This function can be set for each flight condition, and is used to correct the tendency of the model
to change altitude when the rotor is tilted by aileron, elevator, and rudder controls.
ADJUSTABILITY:
• Mixing may be set from 0 to 100% each flight condition.
Goals
Steps
Inputs
Correct the tendency
of the model to
change altitude.
Open
THRO- MIX
function.
to BASIC menu, again to ADVANCE
to THRO-MIX
Activate the function.
to MIX , to ON
Adjust the rate.
Ex:
IDL1
(AIL to TH) 10%
to IDL1 (AIL→TH) , to 10%,
Repeat as needed.
Close
5.3.11 SWASH-RING
This function is to limit movement of swash plate to avoid damage to the SWASH ROB during
operation aileron and ELEVATOR. It is affected in 3D flight. Movement of AILERON and ELEV is
limited in the circle.
