RadioLink AT10II User Manual

Radiolink Electronic Ltd
www.radiolink.com
16
Set up dual/triple rates
and exponential
(D/P,EXP) (Note that in
the middle of the left
side of the screen is the
name of the channel and
the switch position you
are adjusting. D/R may
be set per channel by
choosing the desired
switch and mix rate.
From BASIC menu, choose the
D/R,EXP
to D/R,EXP，press
Choose the desired control, and set the
first (EX: high) rate throws and
exponential.
SwA to up position A
to CH, press , to choose CH2,
press
to D/R
Stick down，press ， to
set ,press
Stick up，press , to
set ,press , to EXP
Stick up, press to set，press
Stick up, press to set，press
Set the second(low)rate throws and
exponential.
SwA to down position
to D/R
Repeat steps above to set low rate.
2.3 AIRPLANE BASIC FUNCTION
2.3.1 Model Select
Model submenu: includes three function that manage model memory: MODEL
SELECT,MODELCOPY and MODEL NAME. Since these functions are related, and all basic
features are used with most models, they are together in the Model submenu.
MODEL SELECT
Totally there are 15 models stored in the system, followed by model name and plane type to use
on tap, thus you don’t need to set every time for different plane. MODEL NAME, MODEL TYPE and
transmitter voltage. Make sure that MODEL TYPE is accomplished with your plane type before flight.
Or it will cause error in servo and rudder.
COPY
Save the present data as another model type, it will be displayed by shadow area to differ from.
When this copy start, the object data will be fully covered including name, type and module type,
and cannot recover.
Caution: when you save the present model type as another, all related data will be copied
including the original model name. Accordingly, if you want to change the model type, the whole
data need to reset, also for model name. The first thing to copy is to change the model type or
