• SWITCH: Any of the positions of any of the 8 switches may be used to activate a mix. Up&Cntr,
Cntr&Dn options allow the mix to be ON in 2 of the 3 positions of a 3-position SWITCH.
• NULL: No SWITCH can turn this mix OFF. This mix is active at all times.
• LOGIC SW (Lsw1 to 3) may be assigned.
• STK-THR: Turn on/off by THROTTLE STICK movement. Trigger point/direction are selectable. Ex:
OFST-to-(gear doors) mix to open gear doors at idle, which is only active if throttle is below half.
• Rate: the percentage of the slave’s range it will move upon maximum input from the master
channel. Ex: RUDDERAILERON mix, 50%. Ail range=1''. When rudder is moved full right, ailerons
move 1/2''.
• Offset: Offsets the slave’s center is relative to the master. Ex: Smoke valve opens wider per
throttle servo position when smoke SWITCH is ON. Smoke servo’s neutral is moved down from
THROTTLE STICK center to the bottom.
Set up a FLAP-ELEV
mix:
ON when SWITCH C is
in the down position.
No elevator movement
when flaps move
up(spoilers),5%elevator
movement when flaps
move down. Link should
be ON if mode has twin
elevator servos.
Otherwise, Link remains
OFF.
Open an unused programmable
mix.(Ex: use PROG.MIX3 since it is
already set up for
FLAP-ELEVATOR)
to BASIC menu, again to ADVANCE
to PROG.MIX PUSH
to MIX, PUSH, to ON, PUSH
Choose master and slave channels.
Optional: set Master as OFST or
VR(A-E)
to Master, PUSH，
todesiredchoice
Set LINK and TRIM as needed.
Assign SWITCH and position.
(Ex: change from E to C, Down)
to SW, PUSH, to SwC
to POSI, PUSH to DOWN
Optional: set switch to STK-THR to
activate mix with THROTTLE
STICK.
to SW, PUSH to STK-THR
to POSI, Throttle Stick to desired
point .
Push 1sec.to set.
