RadioLink AT10II User Manual

Radiolink Electronic Ltd
www.radiolink.com
81
do anything to ‘save’ or store
this data.
Input MULTIROTOR’s
name.
Close
to change the 1
st
character. . move to
next character, repeat as needed. to BASIC.
For proper control operation,
reverse servos as needed.
In the BASIC menu, open
REVERSE.
to REVERSE , to choose REV.
Choose desired servo and
reverse its direction of
travel.(Ex: reverse rudder
servo)
to CH4：RUDD , so REV highlighted, ‘Are
you sure?’ Displays.
Repeat as needed. to BASIC.
Adjust travels as needed to
match model’s recommend
throws(usually listed as high
rates)
From BASIC menu
choose END POINT.
to END POINT,
Adjust the servo’s end
points.(Ex: throttle servo)
Close
to CH1:AILE , VR(A), to desired
percentage. VR(A) to repeat above steps.
Back to choose D/R EXP.
to D/R,EXP
Set up dual/triple rates and
exponential (D/P, EXP)
(Note that in the middle of
the left side of the screen is
the name of the channel and
the switch position you are
adjusting. Two or even
THREE rates may be set per
channel by simply choosing
the desired switch and
programming percentages
with the switch in each of its
2 or 3 positions.
Choose the desired
control, and set the first
(Ex: high) rate throws and
exponential.
to CH ， to CH:2 (ELEV)
SwA screen reads ELEV (UP)
to D/R
Elevator Stick to set rate.
Elevator Stick to set rate. （Normally set the
same as down.
to EXP
Elevator Stick to set rate.
Elevator Stick to set rate.
set the first (Ex: low) rate
throws and exponential.
to D/R SwA to down，repeat to set low rate.
Optional: change dual rate
switch assignment.
to SW ， SwG， SwG to center
position. Repeat steps above to set 3
rd
rate.
Adjust AUX-CH and Knob.
On BASIC menu, then
open AUX-CH function.
to AUX-CH,
Choose CH5 to set
ATTITUDE
to CH5, to ATTITUDE
Assign the switch to
control attitude. Ex: SW3
is SWC，SW2 is SWB
to SW3, , to SWC，
to SW2, , to SWB，
Set the rate in each
attitude. Ex: ATTI is 50%.
to ATTI , to 50%
Change CH6, use VR (D)
to control change other
channels as needed.
to CH6 , to VR(D).
Repeat as needed.
Close
