Chapter 2 Type of Device and Sub-card
2.1 Device type
Explanation of device type:
RC3000-XXX-XX-XX AC
There are 4 types of up-link card for RC3000:
RC3000-OPT-FE RC3000 up-link card of optical interface
RC3000-OPT-2E1 RC3000 up-link card of optical interface
RC3000-4E1 RC3000 line-board of 4 balanced E1 interfaces
RC3000-2E1 RC3000 line-board of 2 unbalanced E1 interfaces
RC3000-2E1-BL RC3000 line-board of 2 balanced E1 interfaces
RC3000-OPT-FE up-link card has an optical interface and a 100M Ethernet interface;
RC3000-OPT-2E1 line-board has an optical interface and 2 E1 ports; RC3000-4E1 line-board has 4
balanced E1 ports; RC3000-2E1 has two CC3 (coaxial cable 3) unbalanced E1 ports, and 2E1 card is
in support of ADM function.
For RC3000-OPT-FE the optical module type decides the device type as following table:
Device type Optical module type
RC3000-OPT-FE -S1 Single-mode Dual-fiber 1310, DSC, 0~25Km
RC3000-OPT-FE -S2 Single-mode Dual-fiber 1310, DSC, 10~50Km
RC3000-OPT-FE -S3 Single-mode Dual-fiber 1550, DSC, 15~120Km
RC3000-OPT-FE -SS13 Single-mode Single -fiber Dual-wavelength T1310/R1550, SC, 0~25Km
RC3000-OPT-FE -SS15 Single-mode Single -fiber Dual-wavelength T1550/R1310, SC, 0~25Km
RC3000-OPT-FE -SS23 Single-mode Single -fiber Dual-wavelength T1310/R1550, SC, 10~50Km
RC3000-OPT-FE -SS25 Single-mode Single-fiber Dual-wavelength T1550/R1310, SC, 10~50Km
For power supply type (after the device type), voltage range is AC 100V~240V and DC -36V~-72V.
2.2 Type of sub-card
Explanation of RC3000 user-card type:
O
p
tical interface t
yp
e of o
p
tical line-
b
oard
U
p
-link card
Device name: multi-service multi
p
lexe
r
Power su
pp
l
y
t
yp
e: AC or DC
Assistant interface t
yp
e of o
p
tical line-
b
oard
