F Without ALS function
5 ALS
N With ALS function
6-8 Reserved
F Relative E1 line works normally
1-4
1-4E1
Loop back
N Relative E1 line is doing the loop back test
F Local loop back
5
Loop back
type
N Remote loop back
SW2
6-8 Reserved Reserved
FFFN Impedance of 3
rd
E1 is 120Ω
1-4
3
rd
E1
impedance
NNNF Impedance of 3
rd
E1 is 75Ω
FFFN Impedance of 4
th
E1 is 120Ω
SW3
5-8
4
th
E1
impedance
NNNF Impedance of 4
th
E1 is 75Ω
Note: F stands for OFF and N stands for ON status. Network management has higher privilege than
DIP switches except optical module type and ALS function configuration. All configuration
information is available through Hyper Terminal. Bit 1-5 of SW1 are set by default in factory
according to optical module type and other bits are all OFF.
