R&S NRP8S User Manual

Remote Control Basics
R&S
®
NRPxxS(N)
174User Manual 1177.5079.02 ─ 10
Table 11-14: Meaning of bits used in the operation sense status register
Bit No. Meaning
0 Not used
1 Sensor initializing
The sensor is being initialized.
5 to 15 Not used
11.3.8.5 Operation Lower Limit Fail Status Register
The CONDition register contains information about whether a displayed value is
below a configured lower limit. The EVENt register indicates whether a measured
value dropped below a limit value since the last readout of the Operation Lower Limit
Fail Status Register. Details of the behavior are defined by the transition register.
Querying the register:
●
STATus:OPERation:LLFail:CONDition?
●
STATus:OPERation:LLFail[:SUMMary][:EVENt]?
Table 11-15: Meaning of bits used in the operation lower limit fail status register
Bit No. Meaning
0 Not used
1 Lower limit fail
The measured value drops below the lower limit value.
5 to 15 Not used
11.3.8.6 Operation Upper Limit Fail Status Register
The CONDition register contains information about whether a displayed value is
above a configured upper limit. The EVENt register indicates whether a limit value was
exceeded since the last readout of the Operation Upper Limit Fail Status Register.
Querying the register:
●
STATus:OPERation:ULFail:CONDition?
●
STATus:OPERation:ULFail[:SUMMary][:EVENt]?
Table 11-16: Meaning of bits used in the operation lower limit fail status register
Bit No. Meaning
0 Not used
1 Upper limit fail
The measured value exceeds the upper limit value.
5 to 15 Not used
Status Reporting System
