4 | Transport
80.06.070_iCombiPro-iCombiClassic_IM_en-GB 21 / 108
NOTICE
Transporting with a transport aid without protection
Transport the unit as far as you can on the pallet. Do not transport the unit
without protection with a transport aid or a similar transport tool. For
protection, you can use a wooden pallet.
x
y
Required door width with transport pallet
Unit size 6-2/3 6-1/1 6-2/1 10-1/1 10-2/1 20-1/1 20-2/1
x (mm) 880 945 1150 945 1150 989 1194
x (inch) 34 5/8 37 1/4 45 1/4 37 1/4 45 1/4 38 7/8 47
y (mm) 930 935 1170 935 1170 969 1174
Y (inches) 36 5/8 36 3/4 46 1/8 36 3/4 46 1/8 38 1/8 46 1/4
Transporting tabletop units with transport pallet
a The packaging material is removed.
a The unit is on the shipping pallet.
a The unit is on the base frame.
1. Transport the unit to its place of installation with the transport pallet.
2. Lift the unit at the lifting points from the transport pallet and place it on its
intended installation surface.
>> The unit is standing on its intended installation surface and is ready for in-
stallation.
Transporting standalone units with transport pallet
Upon delivery, standalone units are on a special, separable transport pallet.
a The packaging material is removed.

Rational CombiMaster Plus Specifications

General

Model	CombiMaster Plus
Manufacturer	Rational
Category	Oven
Cooking modes	Steam, Convection, Combination
Temperature range	30°C to 300°C
Cleaning system	Manual cleaning
Power Consumption	Varies by model
Steam Generator Output	Varies by model
Weight	Varies by model
Dimensions	Varies by model
Control type	Manual
Capacity	10-20 levels (depending on model)
