6 | Electrical connection
80.06.070_iCombiPro-iCombiClassic_IM_en-GB 55 / 108
a The electrical compartment is open.
1. Lead the mains cable through the opening on the rear side to the connection
point in the electrical compartment.
2. Connect the wires to the connector terminals. Adhere to the following col-
our coding.
3. Check that the wires are properly plugged in.
>> The unit is connected to the mains.
Connecting the standalone unit
a A residual current circuit breaker according to the table Power ratings of
different voltage types [}62] is in place.
a The mains lead cleat for the mains cable is tightened.
a The electrical compartment is open.
1. Lead the mains cable through the opening on the underside to the connec-
tion point in the electrical compartment.
2. Tighten the cable screw in the opening.
3. Open the connector terminals with the appropriate tool and connect the
wires. Adhere to the following colour coding.
4. Check that the wires are properly plugged in.
>> The unit is connected to the mains.
Connector terminal colour coding
Connection Wire colour Connector termin-
als
Tool (standalone
units only)
Phase (non-phase-
sequence-depend-
ent)
Grey, black or or-
ange
L1, L2, L3 Allen key
Neutral conductor Blue N Slot screwdriver
Protective con-
ductor
Yellow/green PE Hex socket (Torx)
6.4 Voltage supply (USA and Canada only)
a The unit is switched off.
a All power sources are switched off by way of an external circuit breaker.
a The electrical compartment is open.
1. Check the power supply at the connection.

Rational CombiMaster Plus Specifications

General

Model	CombiMaster Plus
Manufacturer	Rational
Category	Oven
Cooking modes	Steam, Convection, Combination
Temperature range	30°C to 300°C
Cleaning system	Manual cleaning
Power Consumption	Varies by model
Steam Generator Output	Varies by model
Weight	Varies by model
Dimensions	Varies by model
Control type	Manual
Capacity	10-20 levels (depending on model)
