6 | Electrical connection
60 / 108 80.06.070_iCombiPro-iCombiClassic_IM_en-GB
a The mains lead cleat for the mains cable is tightened.
a The electrical compartment is open.
1. Connect the wires to the flat pins. Adhere to the following colour coding.
2. Check that the wires are properly plugged in.
>> The unit is connected to the mains.
Colour coding of flat pins
Connection Wire colour Flat pin
Phase Brown, black or grey L1
Neutral conductor Blue N
Protective conductor Yellow/green PE
6.7 Close the electrical compartment
NOTICE
Clamped cable
When closing the electrical compartment, make sure that no cables or tubes
are trapped.
Unit size 6-2/3 GN
1. Insert the left side panel underneath the unit frame upwards.
2. Press the side panel upwards.
3. Tighten 2 screws on the underside of the side panel and 1 screw on the
rear side.
>> The electrical compartment is closed.
Unit size 6-1/1 GN to 10-2/1 GN
1. Insert the left side panel underneath the unit frame upwards.
2. Press the side panel upwards.
3. Press the side panel inwards in the bottom area.
> The front edge is behind the plastic part and the rear edge is above the
earthing plate.
4. Tighten 2 screws on the rear side of the unit.
5. Put the blind rivet nuts on the front side in the bottom left corner and
tighten them.
6. Insert the grate and press it down.
7. Check that the floor gasket is positioned correctly.
>> The electrical compartment is closed.
