Rational CombiMaster Plus Original Installation Manual

5 | Placement
80.06.070_iCombiPro-iCombiClassic_IM_en-GB 31 / 108
Unit size 6-2/3 6-1/1 6-2/1 10-1/1 10-2/1 20-1/1 20-2/1
z (mm) 214 246 316 246 316 268 338
z (inch) 8 1/2 10 12 1/2 10 12 1/2 11 13
5.1.2 Distance to heat sources
NOTICE
Minimum clearance not adhered to
Place the unit with the minimum clearance to heat sources or open fire
required to prevent any damage to the unit or malfunctions.
NOTICE
High ambient temperature next to the installation site (left side of the unit)
If the temperatures at the installation site on the left side of the unit exceed
80°C [176°F], the heating system will be switched off by the automatic
emergency shutdown.
NOTICE
High ambient temperatures on the rear side of the unit
Do not place any deep-fat fryers or other heat sources by the rear side of the
unit.
Set up the unit with a minimum clearance to heat sources on the left and right.

Rational CombiMaster Plus Specifications

General

Model	CombiMaster Plus
Manufacturer	Rational
Category	Oven
Cooking modes	Steam, Convection, Combination
Temperature range	30°C to 300°C
Cleaning system	Manual cleaning
Power Consumption	Varies by model
Steam Generator Output	Varies by model
Weight	Varies by model
Dimensions	Varies by model
Control type	Manual
Capacity	10-20 levels (depending on model)
