5 | Placement
32 / 108 80.06.070_iCombiPro-iCombiClassic_IM_en-GB
Minimum clearance heat sources
x [mm] 350
x [inch] 14
Heat shield (optional)
If a sufficient distance to the heat source on the left and right cannot be main-
tained, an additional heat shield is available to reduce the thermal load.
The heat shields are available for the following unit sizes and combinations:
Unit sizes 6-2/3 6-1/1 - 10-2/1 20-1/1; 20-2/1
Hitzeschild links x x x
Hitzeschild rechts - x -
Hitzeschild links with
Combi-Duo
x x -
Hitzeschild rechts with
Combi-Duo
- x -
Hitzeschild links with
UV/UV Plus
x - -
Hitzeschild rechts with
UV/UV Plus
- - -
Hitzeschild links with
Combi-Duo and UV/
UV Plus
x - -
Hitzeschild rechts with
Combi-Duo and UV/
UV Plus
- - -
