5 | Placement
80.06.070_iCombiPro-iCombiClassic_IM_en-GB 35 / 108
WARNING
Height-adjustment with unit feet or levelling frame
Risk of burning during operation when loading on rack rails above 1600 mm
[63 inch].
n
Affix the safety label enclosed to the unit.
n
Inform the end user about the hazard of elevated rack rails.
NOTICE
Dirty unit due to broken sealing strip
A sealing strip is affixed to the underside of the unit to seal it at the
installation site. The sealing strip prevents dirt and liquid from getting
underneath the unit. When moving the unit, take care not to damage this
seal.
Pre-requisites
n
When placing the unit on a base frame or base cabinet, be sure to use only
original equipment from the manufacturer for the base frames and cabinets.
n
The unit must only be placed on a level installation surface. Unevenness
across the width of the unit must be no greater than 1 mm [0.04 inches] .
n
If the installation surface is not even, use a levelling frame to level the sur-
face.
n
The installation surface must be clean and free of grease.
n
Set up the unit so that it is freely accessible. The function (e.g. of the cabinet
door) must not be impaired by decorations and cladding. Always observe
the minimum distances.
See also
2 Installation on non-original substructures of the unit manufacturer [}38]
5.2.1 Unit size 6-2/3 GN set up on base frame
a The installation surface is level, clean and free of grease.
a 2 screws are provided for fastening.
1. Lift the unit onto the stand.
2. Position the unit with the spring pins (1). Make sure that the spring pins of
the stand fit into the front holes on the underside of the unit.
