Rational CombiMaster Plus Original Installation Manual

6 | Electrical connection
66 / 108 80.06.070_iCombiPro-iCombiClassic_IM_en-GB
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-2/1 E (3 AC 480 V) 50/60 26.9 22.4 32 B
10-1/1 E (3 AC 480 V) 50/60 22.7 18.9 25 B
10-2/1 E (3 AC 480 V) 50/60 45 37.4 50 B
20-1/1 E (3 AC 480 V) 50/60 44.7 37.2 50 B
20-2/1 E (3 AC 480 V) 50/60 81.7 67.9 100 B
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-1/1 E (3 ph 480 V) 60 13 10.8 20 B
6-2/1 E (3 ph 480 V) 60 26.9 22.4 35 B
10-1/1 E (3 ph 480 V) 60 22.7 18.9 30 B
10-2/1 E (3 ph 480 V) 60 45 37.4 60 B
20-1/1 E (3 ph 480 V) 60 44.7 37.2 60 B
20-2/1 E (3 ph 480 V) 60 81.7 67.9 100 B
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-2/3 (3 NAC 400 V) 50/60 9.2 5.7 10 F
6-1/1 E (3 NAC 400 V) 50/60 15.6 10.8 16 F
6-2/1 E (3 NAC 400 V) 50/60 32.3 22.4 35 B
10-1/1 E (3 NAC 400 V) 50/60 27.3 18.9 32 F
10-2/1 E (3 NAC 400 V) 50/60 54 37.4 63 B
20-1/1 E (3 NAC 400 V) 50/60 53.7 37.2 63 F
20-2/1 E (3 NAC 400 V) 50/60 98 67.9 100 B
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-2/3 (3 NAC 415 V) 50/60 9.5 6.3 10 F
6-1/1 E (3 NAC 415 V) 50/60 15 10.8 16 F
6-2/1 E (3 NAC 415 V) 50/60 33.7 24.2 35 B
10-1/1 E (3 NAC 415 V) 50/60 28.5 20.5 32 F
10-2/1 E (3 NAC 415 V) 50/60 56.5 40.6 63 B
20-1/1 E (3 NAC 415 V) 50/60 56.2 40.4 63 F
