Instructions for Use MPR1 DATALOGGER
Manufacturer: zwo-399EN
RAUMEDIC AG, Hermann-Staudinger-Strasse 2, 95233 Helmbrechts, Germany Rev. 9, 2020-10-16
Page 16 of 98
2.7 Abbreviations
CD Compact Disc
CF Cardiac Floating
CT Computer tomography
EMC Electro-Magnetic Compatibility
ID Identification number
LCD Liquid Crystal Display
LED Light Emitting Diode
LP Long Play memory mode
MPBV German Medical Products Operator Regulations
MPG German Act on Medical Products
MC Measurement check
MRT Magnetic resonance tomography
N.C. Normal Condition
NiMH Nickel Metal Hydride
S.F.C. Single Fault Condition
SN Serial Number
SP Short Play memory mode
SC Safety check
TC Telemetry catheter
2.8 Code designations on the connection sockets of the MPR1
ECG connection socket for ecg cable
Ext. connection socket for device extension (RS232)
Out-1 connection socket for analogue output 1
Out-2 connection socket for analogue output 2
PC connection socket for USB cable
Power connection socket for mains adapter
P1 connection socket for pressure sensor P1
P2 connection socket for pressure sensor P2
P3 connection socket for pressure sensor P3
Temp-1 connection socket for temperature sensor T1
Temp-2 connection socket for temperature sensor T2
2.9 Catheter location and signal designations
ART arterial pressure
CPP Cerebral Perfusion Pressure
DIA diastolic pressure
GP1, GP2, GP3 general pressure parameters (without specific catheter location)
ECG Electrocardiography
HR Heart rate
IBP Invasive Blood Pressure
ICP Intra-Cranial Pressure
ICPA Intra-Cranial Pressure Pulse Amplitude
ICPT Intracranial pressure, telemetrically measured
MAP Median Arterial Pressure
MP1 median pressure P1
MP2 median pressure P2
MP3 median pressure P3
UL upper limiting value
SYS systolic pressure
T1 Temperature T1
T2 Temperature T2
LL lower limiting value
CVP central venal pressure
