Instructions for Use MPR1 DATALOGGER
Manufacturer: zwo-399EN
RAUMEDIC AG, Hermann-Staudinger-Strasse 2, 95233 Helmbrechts, Germany Rev. 9, 2020-10-16
Page 27 of 98
Use approved accessories only. Never try to carry out hardware extensions yourself which are not
supported by the firmware of the MPR1. Every person who connects an additional unit to the signal input
or signal output configures a medical system, and thus he / she shall be responsible for the fact that this
system meets the requirements of standard IEC 60601-1-1.
3.7 PC interface
Type: USB
Number: 1
Where: Figure 2: Connection field
, connection [23]
Application: connection of laptop
Use approved accessories only.
By means of the USB cable (RAUMEDIC article No. 283949-001), this USB interface can be used to
connect a laptop, which by means of the DataView software (RAUMEDIC article No. 296900-001) is used
• for on-line display of the values measured.
• for the extended storage of the values measured on the HDU of the laptop.
• for off-line display of the values saved.
• for the administration of the patient data.
• for data export of the values measured to other data evaluation programs (e.g. MS-Excel).
• for printing out the courses measured.
Please keep in mind that the laptop has to be set up outside of the patient environment.
