The following table indicates how the different alarms are acoustically and optically noticed by the operator.
Alarm
condition
LED [6]
*1
LED [7]
*1
Display Sound
none green off normal none
*2
sensor off yellow „Sensor ?“ approx. 30 s. break
medium
priority
*3
off yellow
value
flashes
approx. 20 s. break
high priority red red
value
flashes
approx. 7 s. break
Table 7: Alarm conditions
*1: See Table 1 in chapter 2.3 Contraindications
*2: Individual actions are indicated by individual short sounds.
*3: Physiological and technical alarm
4.9.7 Verifying the alarm system
The alarm system can be verified at any time. Please observe when verifying the acoustic signal that the
muting / reset key has not switched off the acoustic alarm permanently. To verify the alarm system, proceed
as described in chapter 4.6.2 Device diagnostics
. Please observe when verifying the alarm system that
alarms of high and medium priority are tested according to the table rendered above.
