Instructions for Use MPR1 DATALOGGER
Manufacturer: zwo-399EN
RAUMEDIC AG, Hermann-Staudinger-Strasse 2, 95233 Helmbrechts, Germany Rev. 9, 2020-10-16
Page 25 of 98
3.4 Measurement of the body temperature
Applied part type CF
Type: temperature sensors with thermistor characteristic YSI400, connection
jack plug ¼ inch
Number: 2
Where: Figure 2: Connection field
, connections [27] and [28]
Application: see below
The MPR1 can be used to measure and display up to two temperatures. The temperature channels are
type CF and have been classified as protected against defibrillation.
Use only those accessories for temperature measurement which have been listed in the overview of
accessories.
The following temperature sensors have been approved for MPR1:
NEUROVENT-P-TEMP RAUMEDIC 094268-001
Table 5: Temperature sensors
Specification of the temperature measurement: cf. 11 Technical parameters (Specification)
Recommended accessories: cf. 9 Accessories
The resolution of the temperature measurement is 0.01° Celsius, and thus is higher than the accuracy
mentioned above. The higher resolution has been provided intentionally to recognise short-time
changes in temperature (without the necessity of having to ensure an absolute accuracy of 0.01°
Celsius).
3.4.1 Preparing the temperature measurement
As soon as the temperature sensor has been connected to one of the sockets [27] or [28] and is subjected
to a temperature of at least 15.0° Celsius, the MPR1 will show the room temperature in the respective
temperature channel field [7] of the display.
In this way the function of the temperature sensor can be checked prior to use.
Please observe the instructions for use of the accessories, such as cable, temperature sensor and
catheter. If limitations apply in the permissible measuring range or in the protection against defibrillation,
for example, the said shall have to be adhered to by all means.
Please ensure that the sensor connector is dry and free from impurities.
If the temperature displayed appears to be plausible, you can start monitoring the body temperature of the
patient. It is immaterial to which temperature input the temperature sensors are connected.
After applying the sensors to the measuring point, you have to wait for 2 to 3 minutes until the sensor has
taken up the temperature of the measuring point and it does not change anymore so that the exact
temperature value can be read. Always wait until a constant condition has set in, at which the temperature
no longer rises.
In case of a defective sensor (short circuit or cable cut) no value is displayed, instead the display Sensor?
starts flashing.
For information on placing and handling the temperature sensors, please refer to the respective instructions
for use.
