6.13 Defective fuses
The MPR1 has been equipped with a safety fuse. If the fuse is defective, the MPR1 is no longer operational.
The fuse is accessible when the cover to the battery-pack compartment is open.
When the battery pack compartment is open, there is no protection against penetrating liquids.
The fuse may be replaced by trained staff only. If the apparatus does not operate after the first
replacement, remove the fuse again and take the apparatus to the after-sales service department
for repair.
The apparatus must not be operated when the battery-pack compartment is open.
Prior to closing the battery-pack compartment, check the seal. If it is damaged, it has to be
replaced by a new one.
When closing the battery-pack compartment, please make sure that the cable of the signal
transmitter is not jammed in the sealing area.
The fuse can be obtained from the manufacturer, if necessary. Type of fuse cf. 11.1 Technical data
.
6.14 Reaction to fault messages and indications
When an error occurs, the MPR1 will display a fault code after pressing the Info key, and an info message
is available with recommendations for problem solution.
Fault code
Contents of messages which are displayed after
pressing the Info key
Additional recommendation
Fault P01
The measured pressure P1 (ICP1) is outside of the
adjusted limit values.
The measured pressure P2 (ICP2) is outside of the
adjusted limit values.
The measured pressure P3 (ART) is outside of the
adjusted limit values.
Fault P02
The measured temperature T1 is outside of the set limit
values
The measured temperature T2 is outside of the set limit
values
Fault P03
The calculated CPP is outside of the adjusted limit
values.
Fault S01
The pressure sensor P1 was removed. Confirm this
with OK. If you haven´t removed the sensor, the cause
is most probably a sensor defect. Please check this and
replace the sensor if necessary!
The pressure sensor P2 was removed. Confirm this
with OK. If you haven´t removed the sensor, the cause
is most probably a sensor defect. Please check this and
replace the sensor if necessary!
The pressure sensor P3 was removed. Confirm this
with OK. If you haven´t removed the sensor, the cause
is most probably a sensor defect. Please check this and
replace the sensor if necessary!
Fault S02
The ECG cable has been removed. Confirm this with
OK. If you haven't removed the cable,the cause is most
probably a cable defect. Please check this and replace
the sensor if necessary!
