Instructions for Use MPR1 DATALOGGER
Manufacturer: zwo-399EN
RAUMEDIC AG, Hermann-Staudinger-Strasse 2, 95233 Helmbrechts, Germany Rev. 9, 2020-10-16
Page 79 of 98
Contents of messages which are displayed after
pressing the Info key
Additional recommendation
The temperature sensor T1 has been removed.
Confirm this with OK. If you haven´t removed the
sensor, the cause is most probably a sensor defect.
Please check this and replace the sensor if necessary!
The temperature sensor T2 has been removed.
Confirm this with OK. If you haven´t removed the
sensor, the cause is most probably a sensor defect.
Please check this and replace the sensor if necessary!
The telemetry connection has been interrupted. The
telemetry catheter is maybe located outside o
f the
reader antenna transmission range.
The reader has been separated from the device.
Internal defect in pressure channel P1 (ICP1). Remove
sensor and use another channel if needs be!
Get in touch with the Service
Department.
Internal defect in pressure channel P2 (ICP2). Remove
sensor and use another channel if needs be!
Internal defect in pressure channel P3 (ART). Remove
sensor and use another channel if needs be!
Internal defect in temperature channel T1. Remove
sensor and use another channel if needs be!
Get in touch with the Service
Department.
Internal defect in temperature channel T2. Remove
sensor and use another channel if needs be!
A defect with the data saving has arisen, it is no longer
possible possible to continue recording. Please switch
the equipment off and then on again. Erase memory
The anticipated remaining life of the rechargeable
battery is only
26 minutes. Please recharge
immediately!
Pressed alarm key detected longer than 10 sec.
Probably missoperation or device failure.
A keyboard failure has been detected, keyboard input
was not possible.
Get in touch with the Service
Department.
As well as the reader, a catheter has also been
connected to P1. If you wish
inst
ead of the reader, first remove the catheter and
reader. The connect the catheter.
As well as the catheter ICP1, the reader has also been
connected. If you wish to connect the reader instead of
the catheter, firtst remove the catheter and reader.
Then connect the reader.
No more data are received from the reader. There is
probably a technical defect. Remove the reader from
the device and please contact the service staff.
Get in touch with the Service
Department.
After loss of the telemetry connection there is another
DMI in the receiving range of the reader. If you wish to
continue measuring with this DMI, you must switch the
device off and start a new measurement after switching
The implant probably has a hardware fault.
There is an error in the implant data. A measurement
process cannot be carried out. If possible, use another
