Figure 8: Measurement using the telemetry catheter
Please note that telemetric data transfer requires exact alignment of the reader aerial with the telemetry
catheter and that the bridgeable distance is limited.
17 mm
Reader-
aerial
Telemetric
catheter
Please note that it takes several second to make the connection between the reader and the telemetry
catheter.
