Instructions for Use MPR1 DATALOGGER
Manufacturer: zwo-399EN
RAUMEDIC AG, Hermann-Staudinger-Strasse 2, 95233 Helmbrechts, Germany Rev. 9, 2020-10-16
Page 94 of 98
Telemetry channel pressure
Number of channels: 1
Measuring site designations: ICPT
Measurement ranges; - 40 ... + 400 mm Hg
Pressure value resolution: 1 mm Hg
Accuracy: ± 2 mm Hg
Sampling rate: 5 Hz
Defibrillator protection yes
Analogue outputs
Number of channels: 2
Transferable input values: Invasive pressure twice
Characteristic features: 5 µV / V / mmHg
Measuring range: - 40 ... + 360 mmHg
Resolution: < 0.5 mmHg, typical 0.23 mmHg
Accuracy after zeroing*1: ± 1.5 mmHg in tempered condition (25° Celsius)
Output frequency: 100 Hz
Thermal drift: maximum 0.5 mmHg / K
*1: Zeroing of the downstream monitor
Interface for the expansion of the apparatus
Type: RS232 (V24) + power supply
Application: unit service and optional extension of the apparatus
PC interface
Type: USB
Application: connection of laptop
General data
Type designation: RAUMEDIC MPR 1 DATALOGGER
Mode of operation: continuous operation
Volume of alarm: minimum 45 dB(A) typical 60 dB(A), 1 m, in stand holder
Display: Black/white LCD 320 x 240 pixel (1/4 VGA), 74 x 97 mm
Trend display: optional 4 min., 8 min., 20 min., 40 min., 80 min. or 4 h
Alarm limits: to be selected by menu
Language: German, other language versions optional
Dimensions: approx. 200 x 69 x 150 mm (W x D x H)
Mass: approx. 0.95 kg with battery
Fuse in battery compartment *
2
: type: TR5 / No. 372 / 250V / 1.25 AT / Wickmann
Power supply: internal battery
Type of battery: NiMH, Panasonic HHR210AH-1Z
Operating period: > 12 h (charged, new battery pack, all channels occupied,
illumination off)
Charger / mains unit: Wide range adapter Art. No. 284007-002 or Art. No. 284027-001
Input: 100-240 V / 50-60 Hz / 400-150 mA,
Output: 12 V / 1.5 A, protection class II, IP 40
Class of protection: - class of protection II with internal and external power supply
- type CF IEC 60601-1
- Directive 93/42/EEC Class II b
IP protection class: IP 21 in operation (sockets to the bottom, maximum inclination
20°)
*2: The fuse may be replaced by trained staff only. If the apparatus does not operate after the first replacement, remove the fuse again
and take the apparatus to the after-sales service department for repair. The fuse can be obtained from the manufacturer, if
necessary.
