CHAPTER 2
12 AccuFlow™ Vortex and AccuFlow™ HP+ Installation and Operation Manual
TABLE 1.
System Specifications
TABLE 2. System Plumbing Component Recommendations.
System Specifications Max Flow Rate Tank Pressure Tank Full Level
AccuFlow Vortex System (non-Pump)
50 GPM
1
1. Achieved Based on Recommendations Below
60 PSI >25%
AccuFlow HP+ System (Pump)
80 GPM
2
2. Achieved Based on Recommendations Below
60 PSI >25%
Component Recommendations
Component
Component
Description Size (Qty) Length Additional
Nurse
Trailer and
Cooler
Plumbing
1
Nurse Trailer and Nurse
Tanks
Dual Tanks
NA
2 Nurse Tank Drop Tubes 1-1/2” (2) NA
3
Nurse Tank Withdraw
Valves
1-1/2” (2) NA
Rated capacity 60 gpm
each (2).
4
Trailer Bulkhead
Couplers
2-1/4” Acme
(2)
NA
5
Nurse Tank Main Shut-
off Valves
1-1/2” (2) NA
6
Toolbar Breakaway
Couplers
1-1/2” (2) NA
-
Hoses from Nurse Tank
Withdrawal Valves to
*Trailer Bulkhead
Couplers*
1-1/2” (2)
Minimized
and Equal
Length
*If equipped with
bulkhead couplers*
-
Hoses from *Trailer
Bulkhead Couplers* to
Toolbar Breakaway
Couplers
1-1/2” (2)
Minimized
and Equal
Length
Ensure hose has
enough length to turn
unit without pinching
hose. Ensure hose
does not drag on
ground. Do not attach
hose to tongue of
toolbar or trailer.
7 Cooler Inlets 1-1/2” (2) NA
-
Hose from Toolbar
Breakaway Couplers to
Cooler Inlet Manifold
1-1/2” (2)
Minimized
and Equal
Length
-
Elbows from Toolbar
Breakaway to Cooler
Inlet Manifold
Not
Recommend
ed
NA
Recommend no street
elbows. Sweep elbows
may be used if
necessary.
-
Total Hose from
Withdraw Valve to
Cooler Inlet Manifold
1-1/2” (2)
Less than 25
ft
Sum of all lengths of
hose from withdraw
valve to cooler.
8
Cooler System Outlets 1-1/4” (2) NA
9 Cooler Vapor Outlets 1” (2) NA
Single
Section
-
Hose from Cooler
Outlet to Section
Manifold/Valve
1-1/4” Minimize
