Raven AccuFlow Vortex User Manual

Introduction: Overview 13
INTRODUCTION
Multi Section
10 Section Splitter NA NA
-
Hose from Cooler
System Outlet to
Section Splitters (ID)
1-1/4”
Minimized
and Equal
Length
-
Hose from Section
Splitters to Section
Manifolds/Valves (ID)
1”
Minimized
and Equal
Length
Distribution
11 Section Manifold NA NA
12 Applicator Knife NA NA
-
Hose from Section
Manifold to Applicator
Knife (ID)
3/8”
Minimized
and Equal
Length
-
Hose from Cooler Vapor
Outlet to Vapor Tee (ID)
1” (2)
Minimized
and Equal
Length
Use 1” tee to split the
four vapor rows
Hose from Vapor Tee to
the Vapor Row
3/4” (4)
Minimized
and Equal
Length
Use 3/4” reducers in 1”
tee
13 Vapor Tee (ID) 1” (2) NA
14 Vapor Rows 4 NA
Attempt to have at
least one applicator
knife in between each
vapor row.
Toolbar 15
Toolbar or Applicator
Unit
NA NA
Tractor 16 Tractor or Prime Mover NA NA
Additional
Fittings
-
Additional fittings
needed for installation
NA NA
Schedule 80 steel or
equivalent pressure
rating.
Materials rated and
approved for NH3
service.
Additional
Hoses
-
Additional hoses
needed for installation
NA NA
Pressure rated 250 psi
working, 750 psi burst
(high pressure areas of
circuit)
Materials rated and
approved for NH3
service.
Other
Plumbing
Components
-
Additional plumbing
components needed for
installation
NA NA
Pressure rated 250 psi
working, 750 psi burst
(high pressure areas of
circuit)
Materials rated and
approved for NH3
service.
