CHAPTER 6
64 AccuFlow™ Vortex and AccuFlow™ HP+ Installation and Operation Manual
FIGURE 2. System Bleed and Emergency Shut-off (Side View)
Primary Bleed
Valve
Secondary Bleed
Valve
Vapor Hose
Toolbar
Hose to
Breakaway
Pressure
Gauge
Temperature Gauge
Vortex Cooler
Bleed Circuit Vapor
Hose Connection
Emergency Shut-Off
Valve
Bleed Circuit
Pressure Hose
Connection
Bleed Line
