13.8AIStargetsymbols
Yourmultifunctiondisplayshowsarangeofsymbolstorepresent
thedifferenttypesofAIStarget.
TargettypeDescriptionSymbol
TransmittingtargetTargetismovingorat
anchor(Targetisnot
activated,dangerousor
lost).
ActivatedtargetTargetactivated—
thatis,AISvector
displayed.Vector
line(optional)shows
predicteddistance
travelledwithinagiven
time.
Selectedtarget
Targetselectedwith
cursor.Canview
detaileddata.
Dangeroustarget
Targetswithinspecied
distance(CPA)ortime
(TCPA).Dangerous
targetalarmsoundsif
enabled.Targetredand
ashing.
Uncertaintarget
CalculatedCPA/TCPA
valueuncertain.
Losttarget
Whenthesignalofa
dangeroustargetnot
receivedfor20seconds.
Targetinlatestpredicted
position.Alarmssounds
ifenabled.Target
ashes.
BuddytargetTargethaspreviously
beenaddedtotheBuddy
List.
AidToNavigation(AToN)
target(Real)
AToNtargetisON
position.
AidToNavigation(AToN)
target(Real)
AToNtargetisOFF
position.
AidToNavigation(AToN)
target(Virtual)
AToNtargetisON
position.
AidToNavigation(AToN)
target(Virtual)
AToNtargetisOFF
position.
LandbasestationtargetLandbasestationtarget
isONLINE.
13.9DisplayingdetailedAIStarget
information
Fromthechartorradarapplication:
1.SelectanAIStarget.
TheAIStargetcontextmenuisdisplayed.
2.SelectViewFullAISData.
AISData
ThetablebelowshowstheAIStargetinformationwhichifavailable
willbedisplayedonthemultifunctiondisplay:
•Type
•Status
•Destination
•LastSeen
•ETA
•MMSI
•CallSign
•IMONo.
•Length
•Beam
•Draught
•Heading
•ROT
•Position
•COG
•SOG
•CPA
•TCPA
Note:Availabledataisdependantuponwhatinformationis
beingtransmittedfromthetargetvesselandthetypeofAISunit
connectedtoyoursystem.
152e7/e7D/e95/e97/e125/e127/c95/c97/c125/c127
