4.7Fastheadingconnection
IfyouwishtouseMARPA(radartargetacquisition)functionson
yourmultifunctiondisplayyouneedeither:
•AnautopilotconnectedtothemultifunctiondisplayviaSeaT alk
ng
orNMEA0183.Thecompassisconnectedtothecourse
computerandcalibratedviathepilotcontrolhead;or:
•ARaymarineorthird-partyfastheadingsensorconnectedtothe
multifunctiondisplayviaNMEA0183.
Note:PleasecontactyourdealerorRaymarinetechnicalsupport
formoreinformation.
4.8SeaTalk
ng
connections
ThedisplaycanconnecttoaSeaTalk
ng
system.
ThedisplaycanuseSeaT alk
ng
tocommunicatewith:
•SeaT alk
ng
instruments(forexample,i70).
•SeaT alk
ng
autopilots(forexample,p70withSmartPilotSPX
coursecomputer).
•SeaT alkequipmentviatheoptionalSeaTalktoSeaTalk
ng
converter.
•NMEA2000equipmentviaoptionalDeviceNetadaptorcables.
TypicalSeaTalk
ng
system
S
S
M
M
A
A
R
R
T
T
P
P
I
I
L
L
O
O
T
T
D12 1 76 -2
12 V / 24 V dc 12 V dc + Data
SeaTalk
ng
1 2
6
9 10
8 8
5
7
3
4
1.SeaTalk
ng
instrument—forexample,i70.
2.SeaTalk
ng
pilotcontrolhead—forexample,p70.
3.Transducerpod.
4.Windtransducer.
5.SeaTalk
ng
multifunctiondisplay.
6.Powersupply.
7.SeaTalk
ng
coursecomputer—forexample,SPX-30.
8.Transducerpod.
9.Depthtransducer.
10.Speedtransducer.
SeaTalk
ng
powerrequirements
TheSeaT alk
ng
busrequiresa12Vpowersupply.
Powermaybeprovidedfrom:
•Raymarineequipmentwitharegulated12Vpowersupply(for
example,aSmartPilotSPXcoursecomputer);or:
•Othersuitable12Vpowersupply.
Note:SeaTalk
ng
doesNOTsupplypowertomultifunctiondisplays
andotherequipmentwithadedicatedpowersupplyinput.
Cablesandconnections
41
