Chapter1:Importantinformation
Warning:Productinstallationand
operation
Thisproductmustbeinstalledandoperatedin
accordancewiththeinstructionsprovided.Failureto
dosocouldresultinpersonalinjury,damagetoyour
vesseland/orpoorproductperformance.
Warning:Potentialignitionsource
ThisproductisNOTapprovedforusein
hazardous/ammableatmospheres.DoNOTinstallin
ahazardous/ammableatmosphere(suchasinan
engineroomornearfueltanks).
Warning:Highvoltages
Thisproductcontainshighvoltages.DoNOTremove
anycoversorotherwiseattempttoaccessinternal
components,unlessspecicallyinstructedinthis
document.
Warning:Productgrounding
Beforeapplyingpowertothisproduct,ensureithas
beencorrectlygrounded,inaccordancewiththe
instructionsinthisguide.
Warning:Switchoffpowersupply
Ensurethevessel’spowersupplyisswitchedOFF
beforestartingtoinstallthisproduct.DoNOTconnect
ordisconnectequipmentwiththepowerswitchedon,
unlessinstructedinthisdocument.
Warning:FCCWarning(Part15.21)
Changesormodicationstothisequipmentnot
expresslyapprovedinwritingbyRaymarine
IncorporatedcouldviolatecompliancewithFCCrules
andvoidtheuser’sauthoritytooperatetheequipment.
Warning:Radarscannersafety
Beforerotatingtheradarscanner,ensureallpersonnel
areclear.
Warning:Radartransmissionsafety
Theradarscannertransmitselectromagneticenergy.
Ensureallpersonnelareclearofthescannerwhen
theradaristransmitting.
Warning:Sonaroperation
•NEVERoperatethesounderwiththeboatoutof
thewater.
•NEVERtouchthetransducerfacewhenthesounder
ispoweredon.
•SWITCHOFFthesounderifdiversarelikelytobe
within7.6m(25ft)ofthetransducer.
Warning:Touchscreendisplay
Whenexposedtoprolongedperiodsofdirectsunlight,
thetouchscreendisplaycangetveryhot.Insuch
conditions,avoidusingthetouchscreendisplayand
usetheunit’sphysicalkeysandbuttonsinstead.
Caution:Transducercable
DoNOTcut,shorten,splicethetransducercableor
removetheconnector.Ifthecableiscut,itcannotbe
repaired.Cuttingthecablewillalsovoidthewarranty.
Caution:Powersupplyprotection
Wheninstallingthisproductensurethepowersource
isadequatelyprotectedbymeansofasuitably-rated
fuseorautomaticcircuitbreaker.
Caution:Careofchartandmemory
cards
Toavoidirreparabledamagetoand/orlossofdata
fromchartandmemorycards:
•Ensurethatchartandmemorycardsarettedthe
correctwayaround.DONOTtrytoforceacardinto
position.
•DONOTsavedata(waypoints,routes,andsoon)
toachartcard,asthechartsmaybeoverwritten.
•DONOTuseametallicinstrumentsuchasa
screwdriverorplierstoinsertorremoveachartor
memorycard.
•Saferemoval.Alwayspowertheunitoffbefore
insertingorremovingachartormemorycard.
Caution:Ensurechartcarddooris
securelyclosed
Topreventwateringressandconsequentdamageto
thedisplay,ensurethatthechartcarddoorisrmly
closed.Thiscanbeconrmedbyanaudibleclick.
Caution:Suncovers
•T oprotectyourproductagainstthedamaging
effectsofultraviolet(UV)light,alwaystthesun
coverswhentheproductisnotinuse.
•Removethesuncoverswhentravellingathigh
speed,whetherinwaterorwhenthevesselisbeing
towed.
Caution:Cleaning
Whencleaningthisproduct:
•DoNOTwipethedisplayscreenwithadrycloth,as
thiscouldscratchthescreencoating.
•DoNOTuseabrasive,oracidorammoniabased
products.
•DoNOTuseajetwash.
TFTDisplays
Thecolorsofthedisplaymayseemtovarywhenviewedagainst
acoloredbackgroundorincoloredlight.Thisisaperfectlynormal
effectthatcanbeseenwithallcolorThinFilmTransistor(TFT)
displays.
IncommonwithallTFTunits,thescreenmayexhibitafew(less
than7)wronglyilluminatedpixels.Thesemayappearasblack
pixelsinalightareaofthescreenorascoloredpixelsinblackareas.
Wateringress
Wateringressdisclaimer
Althoughthewaterproofratingcapacityofthisproductmeetsthe
IPX6standard,waterintrusionandsubsequentequipmentfailure
mayoccuriftheproductissubjectedtocommercialhigh-pressure
washing.Raymarinewillnotwarrantproductssubjectedto
high-pressurewashing.
Importantinformation
9

Raymarine c95 Specifications

General

Brand	Raymarine
Model	c95
Category	Marine GPS System
Language	English
