Raymarine c95 - Flush Mounting; Attaching the Rear Bezel

5.3Flushmounting
Youcanmountthedisplayinaushorpanelmountingarrangement.
Beforemountingtheunit,ensurethatyouhave:
•Selectedasuitablelocation.
•Identiedthecableconnectionsandroutethatthecableswilltake.
•Detachedthefrontbezel.
D12 2 71 -1
1.Checktheselectedlocationfortheunit.Aclear,atareawith
suitableclearancebehindthepanelisrequired.
2.Fixtheappropriatecuttingtemplatesuppliedwiththeproduct,to
theselectedlocation,usingmaskingorself-adhesivetape.
3.Usingasuitableholesaw(thesizeisindicatedonthetemplate),
makeaholeineachcornerofthecut-outarea.
4.Usingasuitablesaw,cutalongtheinsideedgeofthecut-outline.
5.Ensurethattheunittsintotheremovedareaandthenle
aroundtheroughedgeuntilsmooth.
6.Drill4holesasindicatedonthetemplatetoacceptthesecuring
screws.
7.Placethegasketontothedisplayunitandpressrmlyontothe
ange.
8.Connectthepower,dataandothercablestotheunit.
9.Slidetheunitintoplaceandsecureusingtheprovidedscrews.
Note:Theappropriatetorquetousewhendrillingdependsonthe
thicknessofthemountingsurfaceandthetypeofmaterial.
Note:Thesuppliedgasketprovidesasealbetweentheunitand
asuitablyatandstiffmountingsurfaceorbinnacle.Thegasket
shouldbeusedinallinstallations.Itmayalsobenecessaryto
useamarine-gradesealantifthemountingsurfaceorbinnacleis
notentirelyatandstifforhasaroughsurfacenish.
5.4Attachingtherearbezel
Therearbezelmustbettedbeforemountingtheunitonthe
suppliedtrunnionbracket.
1.Removethefrontbezel.Refertotheseparateinstructions
providedforthatprocedure.
2.Placethebezelovertherearofthedisplay,ensuringthatitis
correctlyalignedwiththedisplay.Applyrmbutevenpressure
tothebezelalongthe:
i.Outeredges-workfromthesidesupwardsandthenalong
thetopedge,toensurethatitclipssecurelyintoposition.
ii.Inneredges-ensurethatthebezelsitsatagainsttheunit.
D12 183 -2
* = e 7 / e 7D
= c95 / c97 c125 / c127 / e 95 / e 97 / e 125 / e 127
*3
2
1
3.Usethesuppliedscrewstosecurethebezeltothedisplay.
54e7/e7D/e95/e97/e125/e127/c95/c97/c125/c127
