3.7Typicalsystems
Example:Basicsystem
S
S
M
M
A
A
R
R
T
T
P
P
I
I
L
L
O
O
T
T
D12 2 45-1
1 2 3 4 5
SeaTalk
ng
SeaTalk
hs
/ RayNet SeaTalk
hs
/ RayNet
1.Multifunctiondisplay.
2.Raymarinenetworkswitch.
3.Digitalradomescanner.
4.SPXcoursecomputer.
5.Pilotcontroller.
Note:AnetworkswitchisonlyrequiredifmorethanonedeviceisconnectedusingSeaT alk
hs
/RayNet.
Example:BasicsystemwithSeaTalkequipment
S
S
M
M
A
A
R
R
T
T
P
P
I
I
L
L
O
O
T
T
D12 2 46-1
1 2 3 4
SeaTalk
ng
5
6
SeaTalk
hs
/ RayNet SeaTalk
hs
/ RayNet
1.Multifunctiondisplay.
2.Raymarinenetworkswitch.
3.Digitalradomescanner.
4.SPXcoursecomputer.
5.SeaTalkpilotcontroller.
6.SeaTalktoSeaTalk
ng
converter.
Note:AnetworkswitchisonlyrequiredifmorethanonedeviceisconnectedusingSeaT alk
hs
/RayNet.
Planningtheinstallation
