6.13Applications
Chartapplication—providesa2Dor3Dgraphical
viewofyourchartstohelpyounavigate.Waypoint,
route,andtrackfunctionsenableyoutonavigatetoa
speciclocation,buildandnavigateroutes,orrecord
whereyou’vebeen.Chartcardsprovidehigherlevels
ofdetailand3Dviews.
Fishnderapplication—withatransducerand
asonarvariantmultifunctiondisplayorcompatible
DigitalSounderModule(DSM),youcanusethe
shnderapplicationtohelpyouaccuratelydistinguish
betweendifferentsizesofsh,bottomstructure,and
underwaterobstacles.Youcanalsoviewseadepth
andtemperaturedataandmarkpointsofinterestsuch
asshingspotsorwrecks.
Radarapplication—withasuitableradarscanner,
youcanusetheradarapplicationtotracktargets
andmeasuredistancesandbearings.Anumberof
automaticgainpresetsandcolormodesareprovided
tohelpyougetthebestperformancefromyourradar
scanner.
Dataapplication—viewsystemandinstrumentdata
onyourmultifunctiondisplay,forarangeofcompatible
instruments.Usethejoystickortouchscreentoscroll
throughtheavailabledatapages.
Weatherapplication—(NorthAmericaonly).Witha
suitableweatherreceiverconnectedtoyoursystem,
theweatherapplicationoverlayshistorical,live,and
forecastedweathergraphicsonaworldmap.
Thermalcameraapplication—viewandcontrola
compatiblethermalcamerausingyourmultifunction
display.
Videoapplication—viewavideoorcamerasource
onyourmultifunctiondisplay.
6.14Screenoverview
D
12 196 -1
5
4
1
2 3
8
6
7
ScreenitemDescription
1Home—selectthisicontoaccessthehomescreen.
2
Databar—providesinformationaboutyourvesseland
itsenvironment.Thepositionandtypeofinformationin
thedatabarcanbecustomizedfromtheHomescreen>
Customize>DatabarSet-upmenu,ifrequired.
3Menu—selectthisicontoaccessthemenu.Themenu
optionsarespecictotheapplicationthatyouarecurrently
using.Usethetouchscreen(HybridTouchdisplaysonly)
orusetheRotarycontroltoselectmenuitemsandscroll
longmenus.
4Pop-upmenu—menuoptionsaredisplayedwhenyou
selecttheMenuicon.
5
Pop-upmessages—alertyoutoasituation(suchasan
alarm),orunavailablefunction.Pop-upmessagesmay
requirearesponsefromyou—forexample,selectOKto
silencealarms.
6Dialogs—enabledatatobeselected,editedorentered.
Useinmanycommonfunctions—forexample,editing
awaypoint..
7
Contextmenu—providesinformationandoptions
specictoeachapplication.
8
Statusbar—providesinformationspecictoeach
application.Thisinformationcannotbeeditedormoved.
Usingpop-upmenus
Pop-upmenusenableyouconguresettingsandpreferences.
Menusareusedinthe:
•Homescreen—tocongureyourmultifunctiondisplayand
externally-connectedequipment.
•Applications—tocongurethesettingsforthatparticular
application.
Thefollowingdiagramshowsthemainfeaturesofapop-upmenu:
D12 2 81 -1
1
3
2
