2.2Productoverview
Dragony
®
productsarestandaloneFishnderand/
orChartplotterproducts.
D13240-1
Thefollowingproductsareavailable:
ProductFeatures
Wi-Fish
™
•1xCHIRPDownVision
™
channel
•SuppliedwithCPT-DV(CHIRP
DownVision
™
andtemperaturetransom
mounttransducer
•Built-inWi-Fi(displayonAndroid4and
iOS7compatiblesmartdevices)
•Easyballandsocketdisplaymounting
Dragony-4DV
•4.3’BrightallweatherLEDbacklit
display
•1xCHIRPDownVision
™
channel
•SuppliedwithCPT-DV(CHIRP
DownVision
™
andtemperaturetransom
mounttransducer
•Easyballandsocketdisplaymounting
Dragony-4
DVS
•4.3’BrightallweatherLEDbacklit
display
•DualchannelCHIRPDownVision
™
and
CHIRPSonarchannels.
•SuppliedwithCPT-DVS(Combined
CHIRPDownVision
™
,CHIRPsonar
andtemperaturetransommount
transducer
•Easyballandsocketdisplaymounting
Dragony-4
Pro
•4.3’BrightallweatherLEDbacklit
display
•DualchannelCHIRPDownVision
™
and
CHIRPSonarchannels.
•SuppliedwithCPT-DVS(Combined
CHIRPDownVision
™
,CHIRPsonar
andtemperaturetransommount
transducer
•Easyballandsocketdisplaymounting
•Built-inWi-Fi(displayonAndroid4and
iOS7compatiblesmartdevices)
ProductFeatures
•Built-inGNSS(GPS/GLONASS)
receiver
•CompatiblewithLightHouse
™
charts,
Navionics
®
andC-Mapchartsby
Jeppesen
®
Dragony-5
DVS
•5’BrightallweatherLEDbacklitdisplay
•DualchannelCHIRPDownVision
™
and
CHIRPSonarchannels.
•SuppliedwithCPT-DVS(Combined
CHIRPDownVision
™
,CHIRPsonar
andtemperaturetransommount
transducer
•Easyballandsocketdisplaymounting
Dragony-5
Pro
•5’BrightallweatherLEDbacklitdisplay
•DualchannelCHIRPDownVision
™
and
CHIRPSonarchannels.
•SuppliedwithCPT-DVS(Combined
CHIRPDownVision
™
,CHIRPsonar
andtemperaturetransommount
transducer
•Easyballandsocketdisplaymounting
•Built-inWi-Fi(displayonAndroid4and
iOS7compatiblesmartdevices)
•Built-inGNSS(GPS/GLONASS)
receiver
•CompatiblewithLightHouse
™
charts,
Navionics
®
andC-Mapchartsby
Jeppesen
®
Dragony-5M
•5’BrightallweatherLEDbacklitdisplay
•Easyballandsocketdisplaymounting
•Built-inGNSS(GPS/GLONASS)
receiver
•CompatiblewithLightHouse
™
charts,
Navionics
®
andC-Mapchartsby
Jeppesen
®
Dragony-7
Pro
•7’BrightallweatherLEDbacklitdisplay
•DualchannelCHIRPDownVision
™
and
CHIRPSonarchannels.
•SuppliedwithCPT-DVS(Combined
CHIRPDownVision
™
,CHIRPsonar
andtemperaturetransommount
transducer
•Easyballandsocketdisplaymounting
•Built-inWi-Fi(displayonAndroid4and
iOS7compatiblesmartdevices)
•Built-inGNSS(GPS/GLONASS)
receiver
•CompatiblewithLightHouse
™
charts,
Navionics
®
andC-Mapchartsby
Jeppesen
®
16
Dragony–4/Dragony–5/Dragony–7/Wi–Fish

Raymarine Dragonfly-5 DVS Specifications

General

Display Size	5 inches
GPS	Yes
Chartplotter	Yes
Waterproof Rating	IPX6 and IPX7
Transducer	Included
Depth Range	Up to 600 feet (183 meters)
Mounting	Flush mount or bracket mount
Display Resolution	800 x 480 pixels
Dimensions	145 mm x 145 mm x 56 mm
Weight	0.7 kg
