Raymarine Dragonfly-5 DVS User Manual

7.6CheckingtheDownVision
™
application
ProductswhichincludetheDownVision
™
applicationandtheCPT-DVorCPT-DVStransducer
canusetheDownVision
™
applicationtodisplay
underwaterstructureandobjects.
FromtheDownVision
™
application:
1.Checkthedisplay.
Withthetransduceractiveyoushouldseea
scrolling(lefttoright)imagethatshowsthe
bottomstructure,youshouldalsoseeadepth
readinginthetopleftdatabox.
7.7Shortcutspage
Theshortcutspageprovidesaccesstothefollowing
functions:
D12781-3
2
4
5
3
1
1Brightnesscontrol.
2
PowerSavemode—selectingwillactivate
PowerSavemode.
3
Enable/DisableSonar—selectingwillenableor
disabletheinternalsonarandDownVision.
4
EjectSDcard—selecttosafelyremovethe
memorycard.
5
Screencapture—selectingsavesascreenshotto
memorycard.
Openingtheshortcutspage
Withthedisplaypoweredon:
1.PressthePowerbuttononce.
Theshortcutspageisdisplayed.
2.UsetheDirectionalcontrolstohighlightan
option.
3.PresstheOKbuttontoselecttheoption.
Adjustingthedisplaybrightness
1.PressthePOWERbuttononce.
TheShortcutspageisdisplayed.
2.Adjustthebrightnesstotherequiredlevelusing
theTrackpad.
Note:Thebrightnesslevelcanalsobeincreased
bypressingthePowerbuttonmultipletimes.
PowerSavemode
InPowerSavemodeallfunctionsoftheproduct
remainactive,butthedisplayisplacedintoalow
powerstate.PowerSavemodeiscancelledby
pressingaphysicalbuttonorwhenanalarmevent
occurs.
EnablingPowerSavemode
ToenablePowerSavemodefollowthestepsbelow.
1.PressthePOWERbutton.
Theshortcutsmenuisdisplayed.
2.SelectPowerSaveMode.
ThedisplayisnowinPowerSavemode.
3.YoucanwakethedisplayfromPowerSavemode
atanytimebypressingaphysicalbutton.
Note:PowerSavemodeisautomaticallycancelled
ifanalarmeventoccurs.
54
Dragony–4/Dragony–5/Dragony–7/Wi–Fish

Raymarine Dragonfly-5 DVS Specifications

General

Display Size	5 inches
GPS	Yes
Chartplotter	Yes
Waterproof Rating	IPX6 and IPX7
Transducer	Included
Depth Range	Up to 600 feet (183 meters)
Mounting	Flush mount or bracket mount
Display Resolution	800 x 480 pixels
Dimensions	145 mm x 145 mm x 56 mm
Weight	0.7 kg
