6.4Wi-Fish
initialsetup
OncetheWi-Fish
unitisinstalledandconnected
toyoursmartdevice,whichisrunningthelatest
versionoftheWi-Fish
app,itisrecommendedthat
thefollowingtasksarecompleted:
Congureunitsofmeasurefordepthand
temperaturereadings
Setatransduceroffset
Viewtheapp’sHelppages
Familiarizeyourselfwiththeproductusing
SimulatorMode.
TheseoptionsareavailableintheWi-Fish
mobile
app’sMoremenuwhichincludesthefollowing
settings:
Settings
Transducerdepthoffset
Depthunits
Temperatureunits
Simulator
Help
About
.
6.5DepthOffset
Depthsaremeasuredfromthetransducertothesea
bed,butyoucanapplyanoffsetvaluetothedepth
data,sothatthedisplayeddepthreadingrepresents
thedepthtotheseabedfromeitherthekeelorthe
waterline.
Beforeattemptingtosetawaterlineorkeel
offset,ndouttheverticalseparationbetweenthe
transducerandeitherthewaterlineorthebottomof
thekeelonyourvessel,asappropriate.Thensetthe
appropriatedepthoffsetvalue.
D9343--2
1 2 3
1
Waterlineoffset
2
Transducer/Zerooffset
3
Keeloffset
Ifanoffsetisnotapplied,displayeddepthreadings
representthedistancefromthetransducertothe
seabed.
Assigningatransducerdepthoffset
Wi-Fish
app
Followthestepsbelowtoassignadepthoffsetvalue
toyourdepthreadings.
WiththeWi-Fish
mobileappconnectedand
runningonyoursmartdevice:
1.SelecttheMoreicon(threeverticaldots).
2.SelectSettings.
3.SelectTransducerDepthOffset.
4.Adjustthedepthoffsettotherequiredvalue.
46
Dragony–4/Dragony–5/Dragony–7/Wi–Fish
