Raymarine Dragonfly-5 DVS User Manual

6.3Wi-Fish
™
mobileapp
TheWi-Fish
™
mobileappisavailableoniOS7or
greaterandAndroid4orgreater.Theappmustbe
usedtocontroltheWi-Fish
™
sonarmodule.
D13242-2
TheWi-Fish
™
appcanbedownloadedfromthe
relevantappstoreforyourdevice.
ConnectingWi-Fi—Wi-Fish
™
D13198-1
Model No E70290
Product: Wi-Fish
Serial No. 1040009
SSID: 1234567890
Passphrase: ************
EXAMPLE
1.InstalltheWi-Fish
™
appfromtherelevantapp
store.
2.Connectyoursmartdevice’sWi-Fitothe
Wi-Fish
™
unit.
Theproduct’suniquenetworkname,knownas
theSSID(ServiceSetIdentier)andPassphrase
foryourproductcanbefoundontheproductlabel
xedtothebottomoftheunit.Itisrecommended
thatyoutakenoteoftheseandretainsomewhere
safeforfuturereference.
3.OpentheWi-Fish
™
app.
Connectingyoursmartdevice
Yoursmartdevice’sWi-Ficonnectionmustbe
connectedtotheproducttoenableuseofthemobile
Wi-Fish
™
app.
WiththeWi-Fish
™
mobileappinstalledonyour
smartdevice:
D13243-1
3 4
1 2
1.OpentheWi-Fisettingsonyoursmartdevice
andselectyourproduct’sSSIDfromthelistof
availabledevices.
Yourproduct’sSSIDcanbefoundontheproduct
labellocatedonthebottomoftheunit.
2.Enteryourproductpassphrase.
Yourproduct’spassphrasecanalsobefoundon
theproductlabellocatedonthebottomofthe
unit.
3.Yourdevicewillnowconnecttotheunitand
obtainanIPaddress.
4.Onceyourdeviceisconnectedyoucanopenthe
Wi-Fish
™
app.
Wi-Fish
™
45

Raymarine Dragonfly-5 DVS Specifications

General

Display Size	5 inches
GPS	Yes
Chartplotter	Yes
Waterproof Rating	IPX6 and IPX7
Transducer	Included
Depth Range	Up to 600 feet (183 meters)
Mounting	Flush mount or bracket mount
Display Resolution	800 x 480 pixels
Dimensions	145 mm x 145 mm x 56 mm
Weight	0.7 kg
