Raymarine Dragonfly-5 DVS User Manual

9.7Waypointsandtracksstorage
capacity
Thedisplaycanstorethefollowingquantitiesof
waypointsandtracks.
Waypoints
3,000waypoints(splitbetweenupto100
waypointgroups)
Tracks
15tracks(eachtrackcancontainupto10,000
points)
9.8Navigation
Navigatingtothecursor'slocation
InCursormodeyoucansettheChartapplicationto
guideyoutothecursor’slocation.
1.UsetheDirectionalcontrolstomovethecursor
tothedesiredlocation.
2.PresstheOKbutton.
Thecontextmenuisdisplayed.
3.SelectGotoCursor.
Navigatingtoawaypoint
YoucansettheChartapplicationtoguideyoutoa
waypoint.
1.UsetheDirectionalcontrolstohighlighta
waypoint.
2.PresstheOKbutton.
Thecontextmenuisdisplayed.
3.SelectGotoWaypoint.
Navigatingtoawaypointfromthewaypoints
list
FromtheChartapplication:
1.Ifrequired,presstheBackbuttontoentermotion
mode.
2.PresstheOKbuttontoopenthemenu.
3.SelectWaypoints.
TheWaypointslistisdisplayed.
4.Selectthewaypointyouwanttonavigateto.
TheWaypointinformationpageisdisplayed.
5.SelectGoto.
Cancellingnavigationtoawaypoint
1.Selectanypositionanywhereon-screen.
Thewaypointcontextmenuisdisplayed.
2.SelectStopGoto.
3.Alternatively,inthechartapplication,goto:Menu
>Navigate>StopGoto.
Note:Oncenavigationisnolongeractive,the
waypointsymbolreturnstoitsnormalstate,and
thedashedlinebetweenyourvesselandthe
waypointisremoved.
Arrivingatawaypoint
Asyourvesselapproachesthetargetwaypoint,the
waypointarrivalalarmprovidesawarning.
1.SelectOkonthewaypointarrivalalarmpopup
message.
Note:Youcansettheapproachdistance(radius)
atwhichthewaypointarrivalalarmwillsound
usingtheWaypointArrivalalarmlocatedinthe
Alarmsmenu
Accessingthealarmsmenu
Dependingondisplayvariant,theAlarmsmenucan
beaccessedby:
84
Dragony–4/Dragony–5/Dragony–7/Wi–Fish

Raymarine Dragonfly-5 DVS Specifications

General

Display Size	5 inches
GPS	Yes
Chartplotter	Yes
Waterproof Rating	IPX6 and IPX7
Transducer	Included
Depth Range	Up to 600 feet (183 meters)
Mounting	Flush mount or bracket mount
Display Resolution	800 x 480 pixels
Dimensions	145 mm x 145 mm x 56 mm
Weight	0.7 kg
