•selectingTools&SettingsfromtheView
Switcher(Dragony-4Pro,Dragony-5Pro,and
Dragony–7),orby
•selectingSystemSettingsfromtheapplication
menu(Dragony-4DV,Dragony-4DVS,
Dragony-5DVSandDragony-5M).
9.9Chartsettingsmenu—cartography
compatibility
TheoptionsavailableintheChartsettingsmenu
aredependentonthecartographyinuse.Ifthe
cartographyinuseisnotcompatiblethenthemenu
optionwillnotbeshown.
MenuoptionCompatiblecartography
ChartSelection•LightHouseCharts
•Navionics
®
Charts
•Jeppesen
®
ChartDetail•LightHouseCharts
•Navionics
®
Charts
•Jeppesen
®
HighResBathy•Jeppesen
®
ChartOrientation•LightHouseCharts
•Navionics
®
Charts
•Jeppesen
®
Text/SymbolSize
•Jeppesen
®
BoatPosition
•Navionics
®
Charts
CommunityEdits•LightHouseCharts
•Navionics
®
Charts
•Jeppesen
®
SonarLogs•Navionics
®
Charts
COGVector•LightHouseCharts
•Navionics
®
Charts
•Jeppesen
®
DeepWaterFrom
•LightHouseCharts
•Navionics
®
Charts
•Jeppesen
®
Chartapplication
85
