Raymarine Dragonfly-5 DVS User Manual

•C-MAPEssentials
•C-MAP4DMAX
•*C-MAP4DMAX+
Note:*C-MAP4DMAX+cartographywillwork
withDragony
®
productshoweverthe‘+’features
willnotbeavailable.
9.3Chartapplicationcontrols
TheChartapplicationconsistsof2modes:Motion
modeandCursormode.Thebehaviorofsome
controlsaredependentuponmode.Optionsand
settingscanalsobeaccessedfromtheChartcontext
menu.
Motionmode
MotionmodeisthedefaultChartapplicationmode.
InMotionmodetheboatsymbolremainscentered
onscreenandtheChartareamovesaroundtheboat
symbol.
InMotionmodethecontrolsbehaveasfollows:
•pressingthe+buttonrangesin.
•pressingthe–buttonrangesout.
•pressingtheOkbuttonopenstheChartapplication
menu.
•pressingtheBackbuttonopenstheView
switcher.
•pressinganyoftheDirectionalcontrolsenters
Cursormode.
Cursormode
InCursormodetheDirectionalcontrolsareused
tomovearoundtheChartarea.Whenthecursor
reachestheedgeofthescreentheChartareawill
paninthatdirection.
InCursormodethecontrolsbehaveasfollows:
•usingtheDirectionalcontrolsinanydirection
pansthechartareainthatdirection.
•pressingthe+buttonrangesin.
•pressingthe–buttonrangesout.
•pressingtheOkbuttonopensthecontextmenu.
•pressingtheBackbuttonreturnstheapplication
toMotionmode.
Menusanddialogs
Chartapplication
73

Raymarine Dragonfly-5 DVS Specifications

General

Display Size	5 inches
GPS	Yes
Chartplotter	Yes
Waterproof Rating	IPX6 and IPX7
Transducer	Included
Depth Range	Up to 600 feet (183 meters)
Mounting	Flush mount or bracket mount
Display Resolution	800 x 480 pixels
Dimensions	145 mm x 145 mm x 56 mm
Weight	0.7 kg
