Raymarine Dragonfly-5 DVS User Manual

3.10Selectingalocationforthe
transducer
Thisproductissuppliedwithatransommount
transducer.Theguidelinesbelowshouldbefollowed
whenselectingalocationforthetransducer.
Note:Thetransducerisnotsuitableformounting
onvesselswherethetransomisaftofthe
propeller(s).
Forbestperformancethetransducermustbe
installedinalocationwiththeleastturbulenceand
aeration.Themosteffectivewaytodeterminethis
isbycheckingthewaterowaroundthetransom
whilstunderway.
D13184-1
•Mountclosetothekeel(centerline),inaposition
wherethetransducerelementwillbefully
submergedwhenthevesselisplaningandturning.
•Mountasuitabledistancefromthepropeller(s)to
avoidwake.
•Forclockwiserotatingpropellers,mount
thetransduceronthestarboardside,for
counter-clockwise,mountontheportside.
•Onatwinenginevesselmountthetransducer
betweentheengines.
•Turbulencecanbecausedbyanumberofother
factorssuchassteps(1),ribs(2),rowsofrivets
(3)andstrakes(4).Theturbulenceappearsaft
oftheselocations.
1
2
4
3
D12636-1
•Airtrappedunderthefrontofthevesselcantravel
underthehullandappearasaerationaft.
•Ifinstallingonthestepofasteppedtransom,
allowsufcientroomabovethetransducerfor
transducerkickup.
D13185-1
Note:Optimumtransducerlocationwill
varydependingonvesseltype.Optimum
transducerheightandangleshouldbe
obtainedbytestingthetransducerwiththe
vesselinthewater.
Productdimensions–CPT-DVandCPT-DVS
Thetransducer’sdimensionsincludingthetransom
mountingbracketareshownbelow.
D13183-1
65 mm (2.6 in.)228 mm (8.97 in.)
111.2 mm (4.4 in.)
•TheCPT-DVcablelengthis4m(13.1ft.)
•TheCPT-DVScablelengthis6m(19.7ft.)
Planningtheinstallation
25

Raymarine Dragonfly-5 DVS Specifications

General

Display Size	5 inches
GPS	Yes
Chartplotter	Yes
Waterproof Rating	IPX6 and IPX7
Transducer	Included
Depth Range	Up to 600 feet (183 meters)
Mounting	Flush mount or bracket mount
Display Resolution	800 x 480 pixels
Dimensions	145 mm x 145 mm x 56 mm
Weight	0.7 kg
