5.3Cableconnection–DV,DVS,Pro
andWi-Fish
™
Theunithasacombinedpowerandtransducer
cablethatisattachedtothetransducer.
D13190-1
2
4
5
3
1
12 V dc
1.Connectthetransducer/powerconnectorto
therearoftheunitandsecureusingthelocking
collar.
2.Thedrainwireshouldbeconnectedtothevessel
RFgroundpoint.Ifyourvesselhasnoground
pointconnecttothenegativesideofthevessel’s
powersupply.
3.TheNegativewiremustbeconnectedtothe
negativesideofthe12Vdcpowersupply.
4.Afuseholder(notsupplied)MUSTbettedto
thepositivewireusingasuitablyratedinlinefuse
orbreaker.
5.Thepositivewiremustbeconnectedtothe
positivesideofthe12Vdcpowersupply.
5.4Connectingthepowercable-5M
D13193-1
2
4
5
3
1
12 V dc
1.Connectthepowercabletotherearofthedisplay
andsecureusingthelockingcollar.
2.Thedrainwireshouldbeconnectedtothevessel
RFgroundpoint.Ifyourvesselhasnoground
pointconnecttothenegativesideofthevessel’s
powersupply.
3.TheNegativewiremustbeconnectedtothe
negativesideofthe12Vdcpowersupply.
4.Afuseholder(notsupplied)MUSTbettedto
thepositivewireusingasuitablyratedinlinefuse
orbreaker.
5.Thepositivewiremustbeconnectedtothe
positivesideofthe12Vdcpowersupply.
Connectingthecabletothedisplay
D13469-1
1.Ensurethelockingcollarisintheunlocked
position.
2.Ensurethatthecableconnectorisorientated
correctly,rotatesothattheword‘TOP’isonthe
topofthecableconnector.
38
Dragony–4/Dragony–5/Dragony–7/Wi–Fish

Raymarine Dragonfly-5 DVS Specifications

General

Display Size	5 inches
GPS	Yes
Chartplotter	Yes
Waterproof Rating	IPX6 and IPX7
Transducer	Included
Depth Range	Up to 600 feet (183 meters)
Mounting	Flush mount or bracket mount
Display Resolution	800 x 480 pixels
Dimensions	145 mm x 145 mm x 56 mm
Weight	0.7 kg
