Tree Tower
HillorPeak Bridge
Airplane
Car
Skull
DiamondT
Diamond
Quarter
FilledTriangle
9.5Tracks
Atrackisanon-screentrailthatshowsthepassage
youhavetaken.Thistrailismadeupofaseriesof
trackpointswhicharecreatedautomatically.You
cansavethetracktocreateapermanentrecordof
whereyouhavebeen.
D11754-2
Creatingatrack
Fromthechartapplicationmenu:
1.SelectNavigate.
2.SelectStartTrack.
Thestarttrackpopupmessageisdisplayed.
3.SelectOk.
Asyounavigateyourvessel,yourjourneyis
automaticallyrecordedasatrack.
Note:Ifthepowerfailswhilstatrackisbeing
recordedorthepositionxislost,abreakwill
occurinthetrack.
Note:Ifthemaximumnumberoftrackingpoints
isreached,youwillbewarned.Thetrackwill
continuetoberecordedwiththeearliertracking
pointsbeingoverwritten.
4.TocompleteyourtrackselectStopTrackfrom
theNavigatemenu:Menu>Navigate>Stop
Track.
Thetrackstoppedpopupmessageisdisplayed.
5.SelectSave,EraseorCancel.
SaveWillsavethetrackandopentheEdit
trackPropertiesdialogwhereyoucanname
thetrackandchooseacolorforthetrackline.
EraseWillerasethetrack.
CancelWillcanceltheStopTrackaction.
Trackcontextmenu
TheTrackcontextmenushowsthetracklength,
numberofpointsandmenuitems.
Thecontextmenuprovidesthefollowingmenuitems:
StopTrack(onlyavailableduringtrackcreation.)
StopGoto(onlyavailableduringactive
navigation.)
Chartapplication
81
