4.5Finalizingthetransducermounting
Onceyouhaveachievedoptimumperformanceat
thedesiredvesselspeedsthetransducermustbe
lockedintopositiontocompletetheinstallation.
D13197-1
1.Drillthelockingholelocationtakingcarenotto
damagethemountingbracket.
2.Fillthelockingholewithmarinegradesealant.
3.Securethetransducerandbracketbyfully
tighteningall3mountingscrews.
4.Securetheratchetarmbolt,bytighteninguntil
thecompressionwasheriscompressedandthen
addanother1/4turn.Ifthetransducerkicksupat
speedthentightenfurther.
Important:Takecaretoensurethatthepivotbolt
isnotovertightenedasthiswillpreventkick-up
andmaycausedamage.
Mounting
33

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Raymarine Dragonfly-5 DVS and is the answer not in the manual?

Raymarine Dragonfly-5 DVS Specifications

General IconGeneral
Display Size5 inches
GPSYes
ChartplotterYes
Waterproof RatingIPX6 and IPX7
TransducerIncluded
Depth RangeUp to 600 feet (183 meters)
MountingFlush mount or bracket mount
Display Resolution800 x 480 pixels
Dimensions145 mm x 145 mm x 56 mm
Weight0.7 kg
