Transducercableconnectors
Cable
ConnectorDescriptionTransducer
Compatible
unit/display
Black1
keyway
Legacy
CPT-60
Legacy
CPT-70
Legacy
CPT-80
Legacy
Dragony
6
Legacy
Dragony
7
Green3
keyway
CPT-DVS
Updated
CPT-60
Updated
CPT-70
Updated
CPT-80
DVS
Pro
Updated
Dragony
6
Updated
Dragony
7
Yellow3
keyway
CPT-DV
DV
Wi-Fish
Black3
keyway
N/A5
Mpower
connector
5M
Adaptorcables
Adaptorcablesareavailabletoenableconnectionof
theolder1keywayconnectorstothenew3keyway
connectors.
Adaptorcable
Compatible
transducer
Compatible
display/unit
A80331
CPT-DV/
CPT-DVS(3
keyway)toLegacy
Dragony6/
Dragony7(1
keyway)adaptor
cable
CPT-DVS
CPT-DV
Updated
CPT-60
Updated
CPT-70
Updated
CPT-80
Legacy
Dragony6
Legacy
Dragony7
A80332
Legacy(1
keyway)CPT-60/
CPT-70/CPT-80
transducer
toDragony-4
/Dragony-5
andWi-Fish
(3
keyway)adaptor
cable
LegacyCPT-60
LegacyCPT-70
LegacyCPT-80
DV
DVS
Pro
Wi-Fish
Updated
Dragony6
Updated
Dragony7
Legacyandupdatedproducts
Dragony6,Dragony7displaysandCPT-60
/CPT-70/CPT-80transducerdesignshave
beenmodiedtoincludetheimproved3keyway
connectors.
Thetablebelowidentiestheeffectivemanufacturing
datefortheimprovedkeywayconnectors.
Product
3keyway
introductiondate
3keyway
introduction
serialnumber
Dragony6
(E70085)
January2015E700850150001
Dragony7
(E70231)
November2014E702311140712
CPT-60(A80195)
December2014A801951240023
CPT-70(A80278)
January2015A802780150001
CPT-80(A80279)
January2015A802790150001
Cablesandconnections37
